Hydraulic Box and Pan Brake - (BB-7210H)
Stock Number:
BA9-1021002
$30,429.99
Enhanced Bullet 1:
220V 3-phase hydraulic box brake
Enhanced Bullet 2:
10 gauge mild steel capacity
Enhanced Bullet 3:
6-foot length
Enhanced Bullet 4:
Includes 17 fingers from 3" to 6"
Product Overview
The BB-7210H Hydraulic Sheet Metal Box and Pan Brake can bend 10-gauge mild steel sheet metal across its full 6-foot (72”) length. It also handles smaller gauges just as easily.
Baileigh covers this 10-gauge metal brake 1-year parts warranty. Comes with lifetime technical support by phone. You can call our knowledgeable team of reps for machine help and project advice anytime. Questions? Give us a call at 1-920-684-4990 to learn more about this Box and Pan Brake for sale.
Maximum bend angle of 135° with a 1” beam adjustment
Box and pan brake made with top-quality industrial-grade hydraulics for reliability over many years of use
You can operate the hydraulic system in manual or semi-automatic mode to lift the leaf
Adjustable bend auto-stop makes production runs more efficient and ensures repeatability
5 hp motor controls all hydraulic functions and runs on 220-volt 3-phase power
Hydraulic motor attached to a cam lifts and clamps the beam to deliver the extreme pressure required to bend 10-gauge mild steel
Includes 17 hardened 3-piece fingers (6 of 3", 3 of 4", 6 of 5", and 2 of 6") to adjust for just about any size box or pan
6” maximum box depth
Removable bending apron lets you get closer between bends
Fully welded top beam and bending leaf, stabilized with solid steel support rods, keep deflection and twisting to a minimum when you’re bending at full capacity
| Stock Number | BA9-1021002 |
|---|---|
| Beam Adjustment (Front to Rear) (In.) | 1" |
| Maximum Box Depth (In.) | 6" |
| Mild Steel Capacity (Gauge) | 10.0000 |
| Model Number | BB-7210H |
| Prop 65 | Cancer and Reproductive Harm |
| Style (Type) | Hydraulic Box and Pan Brake |
| Warranty | 1 Year |
| Gross Weight | 5010.0 |
| Net weight | 5010.0 |
| Shipping Dimensions (L x W x H) (In.) | 110x44x71 |
| Input Power | 220V / 3-phase |
| Max. Bend (Deg.) | 0 – 135° |
| Motor (HP) | 5 hp |
| Overall Length (In.) | 72” |
