Semi-Automatic Dual Mitering Horizontal Band Saw - BS-24SA-DM
Stock Number:
BA9-1001389
$32,999.00
.
Enhanced Bullet 1:
220V 3-phase power
Enhanced Bullet 2:
18" round capacity at 90°
Enhanced Bullet 3:
Head miters 60° left and right
Enhanced Bullet 4:
1.5" blade width
Product Overview
This dual-mitering band saw doesn’t sacrifice on capacity. With a hydraulic system, cast iron bow, and steel frame, the BS-24SA-DM is built for decades of efficient production.
Questions? Call us at 1-920-684-4990 and talk to a Baileigh expert.
Cuts 18” round or 15” x 24” rectangle at 90° and swivel head miters 60° left and right
Accepts a standard 1.5” blade (included). This width makes the cutting fast and accurate
106 to 317 fpm variable blade speed, allowing for infinite blade speed adjustments. Adjustable speed lets you fine-tune for different materials, like mild steel, bronze, or aluminum
Runs on 220-volt 3-phase power for reliability
Sturdy cast iron vise and bow prevent wobbling and keep cuts accurate and electro-welded steel frame stabilizes the machine, reducing vibrations for many years of accurate cuts
Semi-automatic system with hydraulic down feed speeds up production. You just put the material in place and start the controls. The saw will take care of the rest
Industrial-grade hydraulics open and close the quick-lock vise with flood coolant system that washes away metal chips and helps prolong blade life
Adjustable hydraulic descent pressure helps you achieve faster cut times and longer blade life
You can change the return position of the saw head for faster cycle times between cuts on smaller dimensioned pieces
Patented blade tension device allows you to set the right tension quickly and easily. Line up the black arrow with the green liquid-filled gauge
Stock Number | BA9-1001389 |
---|---|
Blade Guide | Carbide x Roller |
Blade Speeds (SFPM) | 106 - 317 |
Capacity Round 45 | 17.5 |
Capacity Round 90 | 18.1 |
Capacity Round 90 X 45 X 60 | 18" x 15.7" x 11" |
Descent Control | Pressure Assist Hydraulic |
Drive | Belt x Pulley |
Input Power | 220 Volt Three Phase |
Type of Miter Adjustment | Dual Miter Swivel Head |
Miter Angle Range (Deg.) | 0 - 60° Left and Right |
Model Number | BS-24SA-DM |
Motor (HP) | 5 hp |
Prop 65 | Cancer and Reproductive Harm |
Return | Hydraulic |
Shipping Dimensions (L x W x H) (In.) | 111x45x74 |
Solid Rectangle at 90 Degrees (In.) | 17" x 24" |
Table Height (In.) | 31.5 |
Warranty | 1 Year |
Weight (Lbs.) | 3550 |
Gross Weight | 3550.0 |
Net weight | 3550.0 |
